BimmerWorld's TrackCAB (Treehouse) Solid Control Arm Mounts for your E30, E36, or Z3 are a hybrid mount/bushing set designed for drivers needing a solid control arm mounting solution without the added maintenance of spherical joints. The forged bracket (much stronger than CNC'd steel or aluminum) is designed to increase caster for better high-speed stability, creating the same geometry found on an M3*.

The mount incorporates Delrin bushings for a no-deflection design and extended service intervals. Turn-in and brake stability are also highly improved with this solid configuration. Another great feature of the TrackCAB set is the ease of installation - there is no need for a press, making installation a breeze. If used for racing, please verify that replacement of the bushing bracket is legal in your class.

Features:

Solid design without the maintenance of spherical bearings
Incorporates the offset design of Motorsport control arm bushings, increasing caster for better high-speed stability
Installs easily without the need for a press
Can be used on the street, although NVH is increased
Perfect for M50-swapped E30s needing added exhaust clearance
Forged steel construction to handle all the stresses of track and street
Long-wearing Delrin insert is replaceable - inserts available through our online store
Powder coated for corrosion resistance

* - Because the E30 M3 and 1995 M3 have offset control arm bushings, the TrackCABs will not increase caster for these particular models.

When used on 96-99 M3s, the wheel will be moved forward slightly in the wheel well due to additional caster. This may result in tire rub against the inner fender liner. We recommend using 95 M3 or E36 non-M Meyle HD control arms for these applications.

BMW Fitments:

3 Series
E30 (84-91) > 318i
E30 (84-91) > 318is
E30 (84-91) > 325e
E30 (84-91) > 325es
E30 (84-91) > 325i
E30 (84-91) > 325is
E30 (84-91) > M3
3 Series
E36 (92-99) > 318i M42
E36 (92-99) > 318i M44
E36 (92-99) > 318ic M42
E36 (92-99) > 318ic M44
E36 (92-99) > 318is M42
E36 (92-99) > 318is M44
E36 (92-99) > 323ic
E36 (92-99) > 323is
E36 (92-99) > 325i
E36 (92-99) > 325ic
E36 (92-99) > 325is
E36 (92-99) > 328i
E36 (92-99) > 328ic
E36 (92-99) > 328is
E36 (92-99) > M3 (1995)
E36 (92-99) > M3 (96-99)
3 Series
E36/5 (95-99) > 318ti M42
E36/5 (95-99) > 318ti M44
Z Series
E36/7 / E36/8 Z3 (96-02) > Z3 1.9
E36/7 / E36/8 Z3 (96-02) > Z3 2.3
E36/7 / E36/8 Z3 (96-02) > Z3 2.5
E36/7 / E36/8 Z3 (96-02) > Z3 2.8 97-98
E36/7 / E36/8 Z3 (96-02) > Z3 2.8 99-00
E36/7 / E36/8 Z3 (96-02) > Z3 3.0
E36/7 / E36/8 Z3 (96-02) > Z3 M - S52
E36/7 / E36/8 Z3 (96-02) > Z3 M - S54
